CONVENTIONAL EX-PROOF HEAT DETECTOR

APOLLO click to view other products of the brand.

Product Code:EXIS

Orbis IS. Heat Detector

Detection Technologies	Thermistor
Sampling Frequency	Every two seconds
Working Voltage	14.8 V dc - 28 V dc
Wiring	2 Veins, Polarity Sensitive
Power On Time	< 20 second.
Average current-24V	80 μA
Alarm Load Resistance	325 Ω
Alarm Reset Voltage	< 1 V
Alarm Reset Time	1 second.
LED indicators	360º view
Remote output led ( - ) characteristic	Negative feed dependent 4.7 kΩ
Operating Temperature	-40ºC to + 70ºC Operating temperature is limited to. internal safety gas classification. Grade T5: -40ºC to + 45ºC Class T4: - 40ºC to + 60ºC The detector should be protected from condensation or icing conditions
Relative Humidity	0% - 98% RH
Protection Type	IP23D
Standards	EN54-5, CPD, LPCB, MED, LR, DNV-GL, BV, ABS, CCS, KRS, VdS, BOSEC, IECEx, ATEX, PESO, SBSC ve FG ATEX, PESO ve FG
Certificate	BASEEFA Cert No. Bas06ATEX0007X
Material	White flame retardant polycarbonate
Measure / Weight	100 mm diameter x 42 mm height 100 mm diameter x 50 mm height - 70 g detector with base 130 g based detector
